There is a moment in every beginner's electronics journey when the idea of a "closed circuit" stops being an abstract diagram and becomes something you can hold. A continuity tester is the perfect project for that moment, because it does exactly one job: it tells you whether two points are electrically connected. You touch one probe to a wire and the other probe to another wire, and if a small light or buzzer goes off, the path is complete. That's it. No microcontroller, no code, no firmware to flash. Just a battery, a couple of probes, and an indicator.
You can build this entirely on a solderless breadboard, which is why it's a great first project. Breadboards let you push component legs into spring clips without any permanent commitment. If something doesn't work, you pull it out and try again. Grab a 9V battery and snap-on clip, a resistor somewhere between 330 ohms and 1k ohms, an LED, a small piezo buzzer, and two lengths of stiff wire for probes. A short piece of solid-core wire works better than stranded for probes because it holds its shape when you poke at things.
Start by running the red wire from your battery clip to the positive rail on the breadboard, and the black wire to the negative rail. Now place the LED with its longer leg (the anode) into a fresh row. Connect that anode leg to the positive rail through your resistor. The resistor isn't optional here even though it feels like it should be. LEDs will happily burn themselves out in a fraction of a second if you feed them too much current, and the resistor is what keeps them calm.
The cathode of the LED, the shorter leg, goes to a free row. From that same row, run a jumper to one of your probe wires. The other probe wire connects back to the negative rail. The buzzer, if you're using one, goes in parallel with the LED so you get both a light and a sound. Now touch the two probe tips together. The LED should glow and the buzzer should chirp. Separate them and everything goes dark and quiet. That is your tester working.
If nothing happens when the probes touch, don't panic. Check the LED orientation first, because a backwards LED is the single most common beginner mistake. Then check that your battery clip is actually seated on the battery terminals. Then walk your jumpers one at a time and make sure each one is in the row you think it's in. Breadboard rows are easy to miscount by one hole, and that one hole is all it takes.
Once the breadboard version works, you have a genuinely handy tool. Use it to check fuses, test whether a switch is really closing, or trace which end of a mystery cable connects to which pin. It's especially useful when you're salvaging parts from old electronics and want to know if a switch or jack still functions before you bother desoldering it.
When you're ready to make it permanent, move everything to a small piece of perfboard and solder the joints. Mount the probes on short lengths of stiff wire and tape the whole thing inside a small plastic project box with the LED poking through a drilled hole. Add a simple on/off switch in line with the battery so it doesn't drain when it's rattling around in your toolbox. The finished tester fits in a pocket, costs almost nothing, and gives you a real reason to practice your soldering on something that doesn't matter if you get it slightly wrong.
